Remembering to have a center line was a big bonus here. Now we re-use the offcuts from the sides to make the front and rear decks. We first use the offcuts to mark the largest area we can cover then we start fitting angles. This is a lot easier than it might look to the layman. Firstly the angle of the top is drawn in by having the piece of wood upside down.
Align your saw to both angles and presto - a neatly fitted piece of wood. Because we used epoxy a bit of leeway is acceptable and the piece of masking tape was all the clamping pressure we needed to hold it in place.
Screws were added as a secondary joining method later. At the bow front end I am putting a bit more reinforcing to take a tow bar so I can tow it behind a bike, and as a strap down point when carrying it upside down on my roof racks.. The side seat supports are ten inches apart and the front of the aft seat starts 36 inches back from the center and the rear of the front seat starts 28 inches from the center.
I took these measurements and layout from the lazy weekend canoe. There are formulas for working out the spacing of canoe seats if you have the weight of your intended occupants and you have the inclination, feel free to Google them. The side supports are bevelled so that the seat horizontals will be aligned with them. I glued the sides with temporary braces clamped to them to keep them aligned. I made these temporary braces long enough so I could trim them to make the permanent braces.
When putting the permanent braces in ensure you either make them butt securely against the side or unlike me leave just enough room to get a paint brush into the gap to seal the end grain. Pre-sealing with epoxy would be another good option. The height of the notional front of the seat was set as 8 inches from the floor and the height of the back was set using a spirit level while the canoe was kept level with my precision 5 inch wide pavers.
Note the pencil line drawn in to show vertical and that the parts are all numbered as I go to avoid mixing them up as they are all cut to fit. You might notice I replaced the remainder of that temporary center frame with a cross piece or yoke, or thwart. This adds structural integrity and makes a useful point to carry the canoe upside down on your shoulders. Some people take a bit of time to shape the yoke to fit their shoulders and neck if they plan on carrying the canoe for long distances, or maybe just for show.
If I had been thinking ahead my temporary frame would have had a permanent element. The seat slats were added from the center out, spacing the slats with a small jig knocked up from scraps for the purpose. Alternatively you could go with any other seating arrangement you chose including; plywood ; weaving a seat into the frame; an old lawn chair, etc.
I think this canoe would work reasonably as a single person row boat with a central seat and six and a half to seven feet oars. Notionally there is a bit more rocker than required but this can come in useful when rowing because of the shifting center of gravity. Trim off excess wood. Sand and paint before putting in water. You also need to ensure your epoxy or polyester resin does not have any Amine blush or wax left on the surface because paint does not stick to that.
Some epoxies like the Botecote epoxy I used is not prone to those problems. Polyester resin always has a wax residue on the surface, which allows it to cure properly. The paint and colours I am using here are the product of careful selection from the back of my cupboard of leftover paints and from the miss-tint and return section of my local hardware store.
All are just ordinary exterior house paints. The undercoating was applied in two coats, one watered down and one full strength. The outside is Canadian Pine. The trim gunwales and seats is from a "computer prediction" which apparently didn't because it had been returned. Remember to wait after painting for slightly longer than the "touch dry" time before sticking it in the water as paint takes a good while longer to cure fully before being at its full hardness and may re-emulsify i.
A quick dip to christen it should not be too much of a problem but painting the day before a week long canoeing trip is probably going to end in tears. Total weight after painting was about 29 kilograms or about 64 pounds. Now put your life jacket, PFD or whatever else you call it on, put your canoe in the water and paddle it. My son is responsible for the name "Neef the Canoe".
The theoretical way to paddle a two seater canoe is with one person in each seat using single bladed paddles but I found using my double paddles quite easy. The shorter store bought 7 foot long double paddle required more leaning over to get it in the water and clear the sides but the home made seven and a half foot paddle with the smaller blades cleared the sides easily and made the boat scoot along easily.
If you read some paddle fitting guides they fit the paddle to the person but you have to fit the boat as well. The official way to paddle a canoe like this with one person in it is to sit in the front seat facing backwards. Being perverse I tried paddling from the back seat facing forward and found the comfort of the back rest seemed to compensate for the slight extra nose out of wateredness.
Some of that nose out of wateredness is a product of the even rocker in the bottom of the canoe, as the floor of the canoe traces a smooth roughly circular arc. More sophisticated designs like Mik Storer's Quick Canoe tend to have a flat spot in the middle, curving up more abruptly at the end. The wind was gusty rather than than continuously strong and individual gusts woud catch one end of the canoe or other swinging it about, or weathervaning it a bit.
No boat is perfect - even the best of them are just an accumulation of compromises till something convenient pops out. One of these days I will bring an extra camera operator so we can see how good the trim is with me in the back and my son in the front and vice versa and with extra gear etc.
A foregripe is more or less the same thing at the front. A historical debt is also owed to the book 'Building the 6 hour canoe' by Richard Butz I have never read the book myself but many of the web pages above acknowledge their debt to the book. Given the extra seats and things I have included I doubt my version could be made in 6 hours. Disclaimers and warnings You should realise by now that this is a small boat designed for use in sheltered waters.
Please follow all local regulations as for recreational boating. Above all be sensible about the conditions, your abilities and the abilities of your children. Children should be schooled in water safety and taught to swim. You are legally responsible for your own actions and the supervision of children in and around water.
Water is dangerous and cold water more so. I would caution you to wear appropriate floatation vests when canoeing, especially if you have to share your water with power boats. Be careful with sharp tools, power tools, glue and splinters of wood. No ukuleles were harmed in the writing of this instructable. Reply 7 years ago on Introduction. The West Mersey Duck punt is a sail boat with very similar dimensions.
Add outriggers and lots of reserve buoyancy as well if you feel the need for safety. Reply 3 years ago. The dimensions are a simple consequence of the frame and the length of the boards we started with. The mid frame was 32 inches across the bottom and 39 inches across the top. So adding the thickness of our materials makes the canoe just over 32 inches or mm wide at the bottom and around 40inches or mm across the top.
The lengths of the sides are about 16 feet but because they are bent the end to end length is about 3inches shorter making the length 15ft 9 inches or mm. The bottom length of the sides was 4inches shorter at both ends and this makes the bottom 15 ft 1inch or mm end to end. Thee are almost as many ways to cut the bottom as there are ways to cut. I used a Router after gluing the bottom on.
I have seen people who trace the bottom shape, cut it out with an ordinary saw, and then use stitch and glue or screw block and glue.
|
