One thing was evident � people make do with some really dodgy launching trolleys! This view was backed up by walking around the launching area of my local sailing club when all the boats are out on the water and the trolleys are left on the beach. There are some truly awful dinghy launching trolleys in use! A simple, sturdy and functional launching trolley makes using my boats so much easier and more pleasurable. I hope that by sharing this information, I can help others to enjoy their boating more too.
I have also built two wooden launching trolleys, with a third in production and a fourth trolley on order I am building it as a favour for someone at our local sailing club.
Based on my own trial and error, I have a few ideas on how to refine my dinghy launching trolley design further. My second boat launching trolley built for a Sabre sailing dinghy is described in some detail on this page.
Nearly completed Sabre launching trolley � the padding is yet to be glued on the bunks. This will save material and simplify construction. The joint between the rails and the axle case is a simple epoxy glued lap joint. Note that an additional section of wood has been laminated to the outside of the rail. This effectively doubles the surface area of the joint, thereby increasing the strength of the joint.
Laying out the rails in preparation for epoxy gluing to the axle case and toe. Note the additional piece of wood Diy Dinghy Trailer 2.0 to be laminated to the outside of the rail to increase the strength of the joint with the axle case. The force of pulling and pushing the trolley is all transmitted through the junction between the rails and the handle T-piece. Achieving sufficient bracing through this joint is critical. The joint is made up of three elements epoxy glued together. They should be glued together in the following sequence:.
The toe epoxy glued in place, leaving space to accept the handle T-piece. Epoxy gluing the handle T-piece to the rails and toe. Note the rope that I used to hold the top of the T-piece in position while the epoxy glue went off. A nail subsequently removed at the bottom of the T-piece stopped it from sliding out of the slot between the rails. Nail at the bottom of the T-piece to prevent it sliding through the slot between the rails while the epoxy glue goes off. The nail is removed once the glue has gone off.
Brace tying the handle T-piece to the rails. All of the odd angles in this joint can be easily cut using a hand saw and shaped using the angle grinder fitted with a sanding flap disk. I have found this joint to be sufficiently strong even when pulling and pushing the dinghy over soft sand. I regard the toe as being sacrificial � ie, it will wear down over time from being constantly struck on the ground. You may like to protect the toe with a metal plate. The handle is simple.
Drill a hole slightly larger than the chosen size of dowel and simply glue it in place with epoxy mixed with filler to make a glue paste. I recommend drilling the hole before epoxying the handle T-piece in place. Make the handle as thick and as short as you can comfortably hold to minimise the risk of breaking the handle. Also choose a dowel size such that sufficient material is left around the hole drilled through the T-piece.
I initially tried to avoid building bunks for the Minnow trolley, considering them too difficult to construct. In fact, custom moulded fibreglass bunks can be easily built using the following steps:. Epoxy gluing the rough cut front bunk and horizontal cross brace in place. The rear marine plywood rough cut bunk epoxy glued to the back of the axle case and rails. Detail of the joint between the rails, axle case and aft bunk.
Room for improvement: I will not use the horizontal brace for the front bunk on future trolleys. I believe that the marine plywood epoxy glued and filleted to the rails and reinforced with some mm wide, gsm double bias fibreglass tape will be strong enough.
This will permit easier and faster construction, while also eliminating the joint between the fibreglass bunk and the horizontal brace. It also reduces materials and eliminates weight at the front of the trolley. Room for improvement: Make sure the plastic sheet acting as the mould between the hull and the laminated fibreglass bunks is perfectly flat before starting the first layer of fibreglass.
In my case, there was a small fold in the plastic which was ultimately replicated in the surface of the bunk. I figured it was going to be Diy Dinghy Trolley 90 covered by a layer of closed cell foam and marine carpet, so it would not matter in the long run. I am planning to try using pallet shrink wrap the next time I build bunks. Eligible for free delivery. Customer Review. From Our Brands.
